HKXYTECH ROCKWELL Allen-Bradley 2711-B5A2 PanelView Standard Terminal AB 2711B5A2
2711-B5A2,2711B5A2
100% New & Original
Need a Quote?Detailed Information
HKXYTECH ROCKWELL Allen-Bradley 2711-B5A2 PanelView Standard Terminal AB 2711B5A2
Specification of HKXYTECH ROCKWELL Allen-Bradley 2711-B5A2 PanelView Standard Terminal AB 2711B5A2
PanelView Standard terminals feature pixel graphics and
Capabilities of color, grayscale, and monochrome monitors. these sturdy
Electronic operator interface solutions are available in a variety of sizes and
Configured to meet specific application requirements. All use generic
Develop software to simplify programming and improve operator
productivity.
These terminals communicate with PLCs and SLC controllers via EtherNet/IP,
DeviceNet, ControlNet, DH-485, DH+, and remote I/O networks, or use
serial communication.
Additional features supported by the PanelView Standard series include advanced alerting
deal with,
Screen Security, Analog Meter, ATA Memory Card, Common Language
Support and online printing for more intuitive operator control
HKXYTECH ROCKWELL Allen-Bradley 2711-B5A2 PanelView Standard Terminal AB 2711B5A2
| Attribute | PanelView 300 Micro 2711-M3A18L1, 2711-M3A19L1,2711-B5A2 | PanelView 300 2711-K3A2L1, 2711-K3A5L1, 2711-K3A5L1K, 2711-K3A10L1, 2711-K3A17L1 | |||
| Operator input | Keypad | Keypad | |||
| Display type | Monochrome transflective LCD with LED backlight | ||||
| Display area (WxH) | 73 x 42 mm (2.87 x 1.67 in.) | ||||
| Resolution | 128 x 64 | ||||
| Backlight | 100,000 hr LED backlight life | ||||
| Touch screen | — | — | |||
| Keypad description | Stainless steel domed membrane Navigation, function keys Actuation: 2 million presses | ||||
| Keypad function keys | 4 function keys (F1…F4) | 8 function keys (F1…F8) | |||
| Real-time clock | Battery-backed clock timestamps critical data | ||||
| Battery | Not replaceable | ||||
| Application memory | 170 KB application runtime 240 KB nonvolatile memory (application objects plus text and bitmaps) | ||||
| ATA memory card | Not supported | Supported | |||
| Software | PanelBuilder32 software, runs on a personal computer | ||||
| Communication ports | RS-232 (DH-485) RS-232 (DF1) | DeviceNet DH-485 RS-232 (DH-485) RS-232 (DF1) | |||
| RS-232 printer port | — | 1200, 2400, 9600, 19,200 Kbps | |||
| Input voltage, DC | 11…30V DC (24V DC nom) | 18…32V DC (24V DC nom) | |||
| Power consumption, DC | 25 W max (0.105 A at 24V DC) | 10 W max (0.42 A at 24V DC) | |||
| Input voltage, AC | — | — | |||
| Power consumption, AC | — | — | |||
| Weight, approx. | 284 g (10 oz.) | 673 g (1.48 lb) | |||
| Dimensions (HxWxD), approx. | 133 x 111 x 48 mm 5.23 x 4.38 x 1.87 in. | 197 x 140 x 82 mm 7.76 x 5.53 x 3.21 in. | |||
HKXYTECH ROCKWELL Allen-Bradley 2711-B5A2 PanelView Standard Terminal AB 2711B5A2
| Table 5 - Technical Specifications - PanelView Standard 600 Terminals | ||||||||||||||||||||||||||||||||||||||||||||||
| Attribute | PanelView 600 Color 2711-K6C, 2711-B6C | PanelView 600 Color 2711-T6C | ||||||||||||||||||||||||||||||||||||||||||||
| Operator input | Keypad or key/touch | Keypad | ||||||||||||||||||||||||||||||||||||||||||||
| Display type | Color active matrix TFT | |||||||||||||||||||||||||||||||||||||||||||||
| Display area (WxH) | 115 x 86 mm (4.54 x 3.4 in.) | 115 x 87 mm (4.54 x 3.43 in.) | ||||||||||||||||||||||||||||||||||||||||||||
| Resolution | 320 x 234 | 320 x 240 | ||||||||||||||||||||||||||||||||||||||||||||
| Backlight | Field replaceable 50,000 hr 1/2 life at 25 °C (77 °F) | |||||||||||||||||||||||||||||||||||||||||||||
| Touch screen | Touch cells: 128 Actuation: 1 million presses | |||||||||||||||||||||||||||||||||||||||||||||
| Keypad description | Stainless steel domed membrane Keypad, navigation, function keys Actuation: 2 million presses | — | ||||||||||||||||||||||||||||||||||||||||||||
| Keypad function keys | 10 function keys (F1…F10) | |||||||||||||||||||||||||||||||||||||||||||||
| Real-time clock | Battery-backed clock timestamps critical data | |||||||||||||||||||||||||||||||||||||||||||||
| Battery | Field replaceable | — | ||||||||||||||||||||||||||||||||||||||||||||
| Application memory | 190 KB application runtime 240 KB nonvolatile memory (application objects plus text and bitmaps) | |||||||||||||||||||||||||||||||||||||||||||||
| ATA memory card | Not supported | Supported | ||||||||||||||||||||||||||||||||||||||||||||
| Software | PanelBuilder32 software, runs on a personal computer | |||||||||||||||||||||||||||||||||||||||||||||
| Communication ports | EtherNet/IP, DeviceNet, ControlNet, DH+, Remote I/O, DH-485, RS-232 (DH-485), RS-232 (DF1) | |||||||||||||||||||||||||||||||||||||||||||||
| RS-232 printer port | 1200, 2400, 9600, 19,200 Kbps | — | ||||||||||||||||||||||||||||||||||||||||||||
| Input voltage, DC | 18…32V DC (24V DC nom) | |||||||||||||||||||||||||||||||||||||||||||||
| Power consumption, DC | 34 W max (1.9 A at 24V DC) | 24 W max (1.0 A at 24V DC) | ||||||||||||||||||||||||||||||||||||||||||||
| Input voltage, AC | 85…264V AC, 47…63 Hz | — | ||||||||||||||||||||||||||||||||||||||||||||
| Power consumption, AC | 60VA max | — | ||||||||||||||||||||||||||||||||||||||||||||
| Weight, approx. | 2.0 kg (4.4 lb) | 1.0 kg (2.3 lb) | ||||||||||||||||||||||||||||||||||||||||||||
| Dimensions (HxWxD), approx. | 192 x 290 x 116 mm 7.55 x 11.40 x 4.57 in. | 152 x 185 x 96 mm 6.0 x 7.28 x 3.80 in. | ||||||||||||||||||||||||||||||||||||||||||||
