HKXYTECH MTL MTL4541T Safety Barriers MTL4541T Isolation Barrier
MTL4541T
100% New & Original
Need a Quote?Detailed Information
HKXYTECH MTL MTL4541T Safety Barriers MTL4541T Isolation Barrier
MTL4541T
HKXYTECH MTL MTL4541T Safety Barriers MTL4541T Isolation Barrier----MTL Isolation Barrier backplane mounting MTL4500 Isolation Barrier MTL4541T, 2/3 wire Transmitter repeater
General specifications of HKXYTECH MTL MTL4541T Safety Barriers MTL4541T Isolation Barrier:
The MTL4541T provides a fully-floating dc supply for energising a conventional 2- or 3-wire 4/20mA transmitter, which is located in a hazardous area, and repeats the current in another floating circuit to drive a safe-area load. For HART 2-wire transmitters, the unit allows bi-directional communications signals superimposed on the 4/20mA loop current. Separately powered current sources, such as 4-wire transmitters, can be connected but will not support HART communication. The reduced maximum open-circuit voltage permits the use of longer field lines compared to MTL4541.
Features for HKXYTECH MTL MTL4541T Safety Barriers MTL4541T Isolation Barrier:
LED indicator Green: power indication Maximum current consumption (with 20mA signal) 51mA at 24V Power dissipation within unit (with 20mA signal) 0.7W @ 24V dc Safety description Terminals 2 to 1: Vo=22V Io=167mA Po=920mW Um = 253V rms or dc Terminals 3 to 1: Simple apparatus ≤1.5V, ≤0.1A and ≤25mW; can be connected without further certification into any IS loop with an open-circuit voltage <28V
HONGKONG XIEYUAN TECH CO.,LTD is a trading company. We provide not only products but also technical services to our customers. Taking this opportunity, we would like to ask for your further support and encouragement to our company.
Functionally the MTL4500 and MTL5500 range of modules are the same but differ in the following way:
Application for HKXYTECH MTL MTL4541T Safety Barriers MTL4541T Isolation Barrier:
the MTL4500 modules are designed for backplane mounted applications
the MTL5500 modules are designed for DIN-rail mounting.
Ordering codes for HKXYTECH MTL MTL4541T Safety Barriers MTL4541T Isolation Barrier
| ProductCode | Description |
| SM45-55-AI | FSM Safety Manual - Analogue Input Modules |
| SM45-55-AI-A | FSM Safety Manual- Analogue Input Modules- A variants |
| SM45-55-AO | FSM Safety Manual - Analogue Output Modules |
| SM45-55-BI | FSM Safety Manual - Binary Input Modules |
| SM45-55-SAD | FSM Safety Manual - Solenoid / Alarm Driver Modules |
| SM4561_5561 | FSM Safety Manual - Fire Detector Interfaces |
| SM45_5501-SR | FSM Safety Manual – Safety proximity detectors |
| SMx531-82 | FSM Safety Manual - Machine Monitor Interfaces |
| 1.Intro | |
| INA4500 | MTL4500/4600 range Instructions for Safe Use |
| INM4500/4600 | MTL4500/4600 range Instruction Manual |
| MTL4500-5500-ACC | Backplanes, Enclosures & Accessories |
| MTL4500-5500-CS | Common Specifications |
| MTL4500-5500-DS | MTL4500-5500 range Data Set |
| 2.DigitalInput | |
| MTL4501-SR | 1ch DI failsafe solid-state output + LFD alarm |
| MTL4504 | 1ch DI relay output + LFD alarm + phase reversal |
| MTL4510 | 4ch DI solid-state output |
| MTL4510B | 4ch DI multifunction solid-state output |
| MTL4511 | 1ch DI relay output |
| MTL4513 | 2ch DI solid-state output |
| MTL4514D | 1ch switch/prox input, dual output relay |
| MTL4514N | 1 ch switch/prox detector, LFD, phase reversal |
| MTL4514_B | 1ch DI relay output + LFD alarm |
| MTL4516 | 2ch DI relay output |
| MTL4516C | 2ch DI with changeover relay output |
| MTL4517 | 2ch DI relay output + LFD alarm |
| 3.DigitalOutput | |
| MTL4521 | Loop powered solenoid driver |
| MTL4521L | loop powered solenoid driver IIC |
| MTL4523 | Solenoid driver with LFD |
| MTL4523L | Loop powered solenoid driver + LFD |
| MTL4523R | Solenoid driver with LFD |
| MTL4523V-VL | Solenoid/Alarm driver with voltage control |
| MTL4524 | Switch operated solenoid driver |
| MTL4524S | Switch operated solenoid driver, 24V override |
| MTL4525 | Switch operated solenoid driver low power |
| MTL4526 | 2ch switch operated relay |
| 4.AnalogueInput | |
| MTL4541 | 1ch 2/3 wire Transmitter repeater |
| MTL4541A | 1ch Transmitter repeater, passive input |
| MTL4541AS | 1ch Transmitter repeater, passive input, current sink |
| MTL4541B | MTL4041B replacement |
| MTL4541P | MTL4041P replacement |
| MTL4541S | 1ch 2/3 wire Transmitter repeater, current sink |
| MTL4541T | 2/3 wire Transmitter repeater |
| MTL4544 | 2ch 2/3 wire Transmitter repeater |
| MTL4544A | 2ch Transmitter repeater, passive input |
| MTL4544AS | 2ch Transmitter repeater, passive input, current sink |
| MTL4544B | MTL4044 replacement |
| MTL4544D | 2/3 wire transmitter repeater, dual output |
| MTL4544S | 2ch 2/3 transmitter repeater, current sink |
| 5.AnalogueOutput | |
| MTL4546 | 1ch 4-20mA smart isolating driver + LFD |
| MTL4546C | 1ch 4-20mA smart isolating driver + oc LFD |
| MTL4546S | 1ch 4-20mA HART isolating driver + LFD |
| 1ch 4-20mA smart isolating driver + oc LFD | |
| MTL4549C | 2ch 4-20mA smart isolating driver + oc LFD |
| MTL4549Y | 2ch 4-20mA smart isolating driver + oc LFD |
| 6.TemperatureInput | |
| MTL4573 | 1ch Temperature converter, RTD / THC |
| MTL4575 | 1ch Temperature converter, RTD / THC with alarm |
| MTL4576-RTD | 2ch Temperature converter, RTD |
| MTL4576-THC | 2ch Temperature converter, THC |
| MTL4581 | 1ch mV/THC isolator for low-level signals |
| MTL4582B | 1ch resistance isolator to repeat RTD signals |
| 7.PulseandVibration | |
| MTL4531 | 1ch vibration probe interface |
| MTL4532 | 1ch pulse isolator, digital or analogue output |
| 8.FireandSmoke | |
| MTL4561 | 2ch loop-powered, for fire and smoke detectors |
| 9.General | |
| MTL4599 | Dummy isolator |
| MTL4599N | General purpose feed-through module |
